1/4" Raychem DR-25 (Yellow Label) Heat Shrink Tubing (per foot)
Regular price
$1.75
Couldn't load pickup availability
Secure checkout
Friendly support
Hassle-free returns
1/4" Raychem DR-25 (Yellow Label) Heat Shrink Tubing. This is the USA market 'yellow label' DR-25. Priced and sold per foot.
Specifications from the manufacturer Raychem (TE Connectivity)
- Specially formulated for optimum high-temperature fluid resistance, and long term heat resistance. Resistant to aviation and diesel fuels, hydraulic fluids and lubricating oils. Particularly suitable as a jacketing material for military ground vehicle cables and harnesses. It is also well suited for the demands of motorsport cable harnesses.
- Operating temperature range: 75¸C to 150¸C (-103¸F to 302¸F)
- Shrink ratio: 2:1
- Minimum shrink temperature: 150¸C (302¸F)
- Minimum full recovery temperature: 175¸C (347¸F)
Max spool sizes are listed below for reference on all sizes. If you purchase more length than max spool size, it will come with a cut.
- 1/8" = 150'
- 3/16" = 150'
- 1/4" = 150'
- 3/8" = 150'
- 1/2" = 150'
- 3/4" = 100'
- 1" = 100'
